Heat Stabilized Cable Ties
Features & Benefits：
Made of heat-stabilized nylon, these cable ties are specially designed for applications in high-temperature environments. When exposed to elevated temperatures, heats table cable ties ensure secure fastening without breaking or slipping, maintaining consistent mechanical strength and reliability.
Features：
Superior Heat Resistance: Effective in environments up to 130°C
Integrated Structure: Provides consistent performance and durability
High Tensile Strength: Secure locking mechanism for stable fastening
Flexible Packaging Options: Bulk bags of 1,000 pcs or small bags of 50/100 pcs
Applications：
Automotive and engine compartment wiring
Power, petrochemical, and high-temperature equipment fastening
Industrial installations and maintenance in elevated heat environments
Railway, aerospace, and other reliability-demanding sectors
Characteristic：
|
Item |
Details |
|
Material |
Polyamide 6.6 (Heat Stabilized) |
|
Material Brand |
Huafon626F; In vista 4820L |
|
Flammability Of Raw Material |
UL 94-V2 |
|
Humidity Absorption |
2,7%-2,8% (23°C -50% R.H.) |
|
Installation Temperature |
-10°C ~ +105°C |
|
Max Sustainable Temperature For Short Time |
+130°C |
|
Good resistance to bases, oils, greases, oil derivatives, chlorinated solvents. Limited resistance to acids. Not resistant to phenols. Carbon black addition gives a better UV resistance (only for Black Cable Ties) |
|
Parameter:
|
Item No. |
Width |
Length |
Max. Bundle Dia. |
Min. Tensile Strength |
Package |
Material |
|||
|
(mm/inch) |
(mm/inch) |
(mm) |
(inch) |
(N) |
(kg) |
(lbs) |
|||
|
TSB-100M |
2.5(0.098) |
100(3.94) |
22 |
0.87 |
80 |
8.2 |
18 |
100 |
PA66 |
|
TSB-150I |
3.6(0.142) |
150(5.91) |
35 |
1.65 |
180 |
18.2 |
42 |
100 |
PA66 |
|
TSB-200I |
3.6(0.142) |
200(7.87) |
50 |
2.56 |
180 |
18.2 |
42 |
100 |
PA66 |
|
TSB-200ST |
4.8(0.189) |
200(7.87) |
50 |
1.97 |
222 |
22.6 |
50 |
100 |
PA66 |
|
TSB-300ST |
4.8(0.189) |
300(11.81) |
70 |
3.15 |
222 |
22.6 |
50 |
100 |
PA66 |
|
TSB-370ST |
4.8(0.189) |
370(14.57) |
98 |
3.86 |
222 |
22.6 |
50 |
100 |
PA66 |
|
TSB-370HD |
7.6(0.299) |
370(14.57) |
98 |
3.86 |
560 |
55.6 |
130 |
100 |
PA66 |
